ERGO BEAR FG362 S/S -BE10VL -100 ltrs

Product Status : Pre-Order

These are mixers to handle large-scale needs – for production contexts where time and efficiency translate into a lot of money. Where hygiene requirements demand easy and extremely effective cleaning. Production where many different employees need to be able to operate the machine without having received instructions. Employees who avoid strenuous lifting and working positions, because Varimixer ERGO has a ground-breaking ergonomic design.

Raising the height of the mixer has made room for the bowl to be lowered enough to come free of the tool. This means that the bowl can be removed and a new one wheeled in without having to remove the tool. All work at Varimixer ERGO is done with a straight back. There is unhindered access to changing tools at the correct ergonomic working height.

Two arms lock the bowl in place, raise it to the mixing position and then lower it again. No manual lifting. The machine can only be started when the bowl is in place. Sensors in the arms ensure this. It is not necessary to watch the mixing process. When the time is up, the control system lowers the bowl, so the tools can drip off directly into the bowl.

The detachable safety guard is made of CE-certified plastic and is easy to attach and dishwasher safe. Varimixer ERGO can also be fitted with a sealed stainless steel guard which protects against dust and splashing.

Choose between variable speed control, fixed speeds or up to 20 programs with their own processes. All operations are controlled from the intuitive, angled control panel with responsive piezo push button technology. The panel is easy to clean and is dustproof and waterproof.

The general design caters for optimum hygiene and easy cleaning. The standard models can be washed in line with the IP53 standard. By fitting a waterproof stainless steel mixer head and other modifications, the ERGO series can be upgraded to IP54, so the entire machine can be hosed down.

Ergo function ensures quick and easy changeover of bowl and tools with no manual lifting
- Manufactured in hygienic stainless steel
- New horizontally-opening safety guard for easy cleaning
- Frequency converter for more power and durability
- Stainless steel control panel
- Bowl hoist is 40% faster
- Special air valve for improved ventilation
- New improved bowl ring
- Piezo button technology for easy access
- Stores 20 Remix programmes for simple operation
- IP-53 as standard
- New VL-4 control panel as standard

Highly advanced industrial mixer, designed so that the bowl and tools can be changed in the most ergonomic way possible, resulting in greater production capacity.

Supplied with a 100 L bowl along with a whip with stainless steel wires and a beater in aluminium (food grade).

The hygiene of the new mixer is also first class, and the stainless surfaces ensure rapid and effective cleaning of ALL parts of the machine.

The safety guard which is easily removed can be cleaned in a dishwasher.

The design of the ERGO 100 is logical and simple, with fewer moving wear parts and tried-and-tested, reliable technology.

Also on the plus side are the short processing times and the high level of efficiency achieved thanks to the faster change of bowl – without manual lifting!

With the optional extras removable stainless steel closed dust guard and watertight planetary head in stainless steel, the ERGO 100 can adapt to requirements of any customer.

With an ERGO 100, your company is assured of a stable, reliable tool which, with rapid change of bowl, great flexibility, clarity of design and a cleaning-friendly surface, assures your company of a profitable investment and will equip your employees with an ergonomic, user-friendly machine for many years to come.

Used extensively in industrial production units, catering industry, bakeries, in the fast food industry.

VARIMIXER ERGO 100 STANDARD White powder coated 1 bowl 100 liter in stainless steel 1 beater in aluminium with double pin 1 hook in stainless steel with double pin 1 whip with stainless steel wires with double pin Removable safety guard in plastic – CE-certified Separate removal of bowl and tool Digital timer and emergency stop Voltage: 3 ph, 400V, 50 Hz with ground. 4.000 W

VARIMIXER ERGO 100 STANDARD TECHNICAL DATA Volume 100 l Effect 4.000 W Standard voltage* 400 V Net weight 428 kg H x W x L 2029 x 762 x 1206 mm Variable speed 47 – 257 RPM Phases 3 ph IP code IP53 IP code upgrade package IP54

CAPACITIES Egg Whites 15 l Whipped cream 45 l Mayonnaise 80 l Herb butter 75 kg Mashed potatoes 65 kg Bread dough (50% AR) 58 kg Bread dough (60% AR) 70 kg Ciabatta dough (70% AR) 75 kg Muffins 60 kg Layer cake base 25 kg Meatball mix 75 kg Icing 70 kg Doughnut (50% AR) 60 kg

VARIMIXER ERGO 100 MARINE VERSION Stainless steel execution, water cover at air ventilation, slottet free screws, full welded stainless steel knees, gasket at the rear plate, gasket at front panel and top cover. Complies with USPHS. Voltage: 3 ph, 440V, 50 Hz with ground. 4.000 W 3 ph, 480V, 50 Hz with ground. 4.000 W
